Senseca HD2FO1-025GM025-959067 Flow Switch
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
959067
Indicator option: With side measurement display O1
Nominal diameter: DN 25 - G 1
Connection type: Female thread
Connection material: Brass CW614N nickel-plated
Pressure resistance: PN 200
Seal: NBR
Media temperature: -20 ... +120 °C
Environmental temperature: -20 ... +50 °C
Switching range oil: 2.5 ... 25 l/min oil 30 ... 330 mm²/s
Switching head: Plastic, flat head
Adjustment: Oblong hole
Electrical connection: Plug DIN 43650-A / ISO 4400
Electrical contact: Reed switch
Max. contact load: 120 V AC 0,18 A 5 VA / 175 V DC 0,25 A 5 W
Connection diagram: Changeover, connection diagram no. 0.213
Protection type: IP65
Flow direction: Horizontal from the left
Display range: 2.5 ... 30 l/min oil30 ... 330 mm²/s
Positioning of indicator: Top
Number of switching heads: 2-time
