Negele
Negele HSM-P-2 Pt100-Simulator
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
General Function
The Pt100 simulator hsm-p and hsm-p-2 serves for checking and calibrating measurement and control instrumentation having a Pt100 input. The rotary selector enables a total of 23 temperature values to be simulated in the range 100...+600°C (-20...+200°C on hsm-p-2), a fixed resistance being incorporated for each temperature value. By means of the trimmer integrated the temperature can be continuously varied in the range -40...+200°C in the switch position "var", thus enabling e. g. min/max seting and switchpoints of digital displays to be easily checked.
Features
• Pt100 simulation with 23 fixed temperature values
• two temperature ranges -20...+200°C and -100...+600°C
• special range on request
• continuously variable temperature simulation by trimmer
• handy, lightweight instrument
• easy to use
