Negele FMQ Magnetic-Inductive Flow Meter

Magnetic inductive flow and volume measurement of media with a minimum conductivity >5 µS/cm

For liquids, mash and pastes with solids content < 5%Very high accuracy ±0,5 % ±2 mm/s and reproducibility also with low flow rate, ideal for dowing and filling applicationsSuitable for flow rates of 30 l/h to 640 000 l/hCIP/SIP cleaning to max. 130 °C (max. 30 minutes)Large selection of process adapters (optional)Incl. optical status indicator, optional displayIncl. material certificate for pharmaceutical version3-A conformity for version with process connection SS, TC and HHCompact electronics with housing in stainless steelVacuum proof PFA coating for pig cleaning and maximum resistance to aggressive mediaTechnical SpecificationProcess ConnectionAseptic flange | Aseptic thread | FG hygienic flange | DIN flange | welded flange | Tri-Clamp | Varivent | SMS | Dairy tubeInsertion lengthStainless steel 1.4404 (316L) | 1.4435 Ra?0.4 ?m (electropolished) | Tube PFAMeasuring range"0,1…10 m/s 30…640.000 l/h"Accuracy±0,5% ± 2mm/sAvailable versionsCompact | RemoteTemperature range process0…100 °CTemperature range CIP/SIP130 °C / max. 30 Min.Operating pressuremax. 17 barCommunication4…20 mA
