Enerpac RAC206 Aluminum Hydraulic Cylinder
Ask for Stock
Contact with us! 24 business hours (excluding weekends and holidays) to confirm stock status and estimated delivery time.
Model: RAC206 | ECCN: EAR99 | Harmonization: 8412210075
Series: RAC | Product Line: Industrial ToolsComposite bearings prevent metal-to-metal contact, increasing cylinder life and resistance to side-loads of up to 10%Hard coat finish on all surfaces resists damage and extends cylinder lifeFor protection against load-induced damage, a saddle is standard on all models and a steel baseplate is standard on models 20-ton and above.Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacityHigh-strength return spring for rapid cylinder retractionCR-400 coupler and dust cap included on all modelsAll cylinders meet ASME B-30.1 standardsSpecificationsUnits:ImperialMetricMaximum Operating Pressure (psi)10,000Capacity Class (tonnage)20Maximum Cylinder Capacity Advance (short tons)24.2Stroke (in)5.91Collapsed Height A (in)10.79Extended Height B (in)16.7Return TypeSingle-Acting, Spring ReturnPlunger TypeSolidMaterialAluminumCylinder Effective Area Advance (in2)4.83Oil Capacity Advance (in3)28.55Surface TreatmentAnodizedCouplerCR400 CouplerWeight (lbs)10.1
Series: RAC | Product Line: Industrial ToolsComposite bearings prevent metal-to-metal contact, increasing cylinder life and resistance to side-loads of up to 10%Hard coat finish on all surfaces resists damage and extends cylinder lifeFor protection against load-induced damage, a saddle is standard on all models and a steel baseplate is standard on models 20-ton and above.Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacityHigh-strength return spring for rapid cylinder retractionCR-400 coupler and dust cap included on all modelsAll cylinders meet ASME B-30.1 standardsSpecificationsUnits:ImperialMetricMaximum Operating Pressure (psi)10,000Capacity Class (tonnage)20Maximum Cylinder Capacity Advance (short tons)24.2Stroke (in)5.91Collapsed Height A (in)10.79Extended Height B (in)16.7Return TypeSingle-Acting, Spring ReturnPlunger TypeSolidMaterialAluminumCylinder Effective Area Advance (in2)4.83Oil Capacity Advance (in3)28.55Surface TreatmentAnodizedCouplerCR400 CouplerWeight (lbs)10.1
